Xtm light bar wiring diagram. The kit contains an led onoff toggle switch lamp connectors crimping terminals in line relay holder fuse holder with 20a fuse and cable cutters. Nsv led light bar for the toyota tundra install steps duration. Before we get started take note of this relay diagram on how to wire up the switch to your led light. You can visit our online store if you are from north america and would like to purchase our products online. Stedi plug and play driving light wiring harness review wild touring duration. Led light bar wiring harness diagram 3 wire led light bar wiring diagram illuminator led light bar wiring harness diagram led light bar wire diagram every electric arrangement is made up of various different components.
Aftermarket driving lights like spot lights and led light bars offer the ultimate driving light solution for every vehicle. Find out how easy they are to install. For this guide we will be tapping this led light bar to achieve superior lighting in dark off roading situations. This is a general installation guide on how to wire a relay harness and switch kit. Assortment of led light bar wiring diagram. Each component ought to be placed and linked to other parts in specific manner.
85 connects to the power source that you want controlling the switch. 85 and 86 can be reversed. Wild touring 17475 views. If not the structure will not function as it should be. These instructions apply to any car but for the sake of this guide we will be using the ford f 250 as a reference car to wire an led light bar. Make sure your lights are wired in correctly and wont let you down.
A wiring diagram is a streamlined standard photographic depiction of an electric circuit. Now with the plugs that connect to the lights if you are using a light bar only one of the plugs needs to be connected. This is your guide on how to install a universal relay harness wiring set with an onoff switch. This wiring kit will work with any led light product such as the ford f 150 led light bar and makes them easy and safe to work with. For example you could splice a wire off your high beam wire or off your backup light wire 86 connect to a ground. If you are wiring up spot lights connect a plug to each light.
The second plug can be taped up out of the way or you could use this wire for an additional light bar. Find a suitable pathway from the relay to your driving lights which is clear of heat and moving objects and connect using the pre fitted waterproof connector. Remove your high beam plug from the rear of the headlight and connect it to the piggy back adaptor supplied.
