Crankshaft Camshaft Position Sensor Testing Done The Easy Way
Crank sensor wiring diagram. The cam and crk sensors are types of speed. Touch one of your meter probes to either one of the sensor wires and the other to the other wire. Crank the engine for a few seconds. This video is dedicated to cam and crk sensor testing and operational parameter but from an electrical and wiring diagram interpretation point of view. All three wires connect directly to your dodge dakota or durangos fuel injection computer. Have your helper crank or start the engine.
Crankshaft position sensor wiring diagram. Brnyel wire feeds chassis ground. Crank sensor wiring diagram 2001 2005 17l honda civic. Then using the meter red lead back probe the black ground wire at the harness connector or ckp sensor. Your dmm should register about 200mv to 300mv. Crank sensor wiring issues.
Pin a is 12v pin b is ground and pin c is signal. Pink purple and yellow. 3 wires on mine. If neither wire has current theres a failure in the sensor circuit. Ask an assistant to crank the engine for a few seconds. This means that one wire feeds it with power one wire feeds it ground and the other takes the ckp signal to the computer.
Learn how to access vehicle repair guides and diagrams through autozone rewards. Sign up today to access the guides. The illlustrations and info in this page apply only to 1996 1997 1998 dodge ram pickups vans and dakota with a 39l 52l or 59l gasoline engine that use the 3 connector pcm. Yelblk wire feeds 12 volts from pgm relay. A wiring diagram makes it easier to check for shorts to ground or power and of course check for continuity between the crank sensor and the pcm. Pink is 12v yellow is signal and purple is supposedly groundsignal return.
Now touch your dmm red lead to the green signal wire on the harness connector or ckp sensor. Dec 24 2011 327am. The crank sensor is a 3 wire hall effect sensor. Crankshaft position sensor wire color id and description. The connector on the sensor itself has male spade terminals. You should be able to tell from a wiring diagram a good one which wire goes to which terminal.
Blu wire carries crank signal to pcm.
