Remote keyswitch wiring 44 figure 3 22. Vista 128bpt vista 250bpt vista 128bptsia commercial burglary partitioned security system with scheduling user guide 800 06905 610 rev.
Keypad Stops Working After 5 Button Presses Doityourself
Vista 128bpt wiring diagram. Sia cp quick reference chart. Recommendations for proper intrusion protection for proper intrusion coverage sensors should be located at every possible point of entry to a home or. Common rules regarding the polling loop are listed below. Connecting the backup batteries 56 vista 128fbpt vista 250fbpt summary of connections diagram inside back cover. Wiring the vistakey 48 figure 3 25. Unshielded wire is preferable to shielded wire wire in a metal conduit.
Vista 128bpt summary of connections diagram69 vista 250bpt summary of connections diagram70 vista 128bptsia summary of connections diagram 71 sia cp 01 quick reference chart the minimum required system for sia cp 01 is a vista 128bptsia control one of the following model keypad. The vista 128bpt and 250bpt have flexible wire length limits outlined in the charts below based on current draw and wire gauge and whether or not the wire is shielded. All sia related information for the vista 128sia is included in the supplement. To program the vista 128sia you must use the supplement in conjunction with this manual. A 2 wire polling loop provides both current 128ma and data. The vista 128fbpt control is suitable for fire only applications as well as for installations requiring integrated fireburglary systems.
Many features are available that extend the applications of the vista 128bpt while simplifying end user operation. Installation manual for the honeywell vista 128bpt and 250bpt wired control panels. K5894v5 604 rev a ademco vista series vista 128bpvista 250bp vista 128sia commercial burglary commercial burglary partitioned security system partitioned security. Wiring communicator to keypad terminals 46 figure 3 24. Wiring burglary panic and smoke detector devices to. All items labeled sia guidelines in the manual pertain to the vista 128bp and vista 250bp only.
It is the perfect solution for medical and professional office buildings churches and synagogues banks schools strip malls and factory or warehouse environments. For help installing your 128bpt or 250bpt call 888 818 7728. Differences between the vistabptvistabptsia and the drawings diagrams engineering sheets or similar materials used in connection withinstallation and setup guide vistafbp vistafbp summary of. Remote keypad sounder wiring 44 figure 3 23. The vista 128bpt is a powerful member of the honeywell family of commercial alarm panels integrating burglary cctv and access control functions.
