Wire gauges in series from a positive accessory to a source which is not already overloaded with fans air conditioning and such. Refer to the wiring diagram diagram g.
Siemens Vdo Vehicle Controls Manualzz
Vdo water temperature gauge wiring diagram. Installation instructions 1 caution. Coolant temperature oil temperature oil pressure fuel level and speed. Vdo water temperature gauge wiring diagram. Temperature gauge pressure gauge rudder angel gauge trim gauge fuel gauge fresh water gauge for level type sensor tu00 0752 5207102 1 6 3 technische änderungen vorbehalten technical details subject to change tu00 0752 5207102 gb if the instrument is mounted flush ie from the back so that the instrument glass and the panel form one. Connect a wire from pin 5 to a constant 12 or 24 volt source. The final ground run using 14 gauge wire should be connected to a good.
All in one digital display system. Always disconnect battery ground before making any electrical connections. Read these instructions thoroughly before making installation. Connect the wire from pin 4 to a switched 12 volt or 24 volt source. Vdo water temp gauge see more like this. Fc water temperature gauge use with vdo sender 12v spade connection learn more viewline ivory fc water temperature gauge 1224v.
If in doubt please contact your dealer or vdo. The ohm range of the sender and the gauge must match. Do not deviate from assembly or wiring instructions. We continue to work to deliver the functionality durability and high quality finish that have earned our products a best in class reputation worldwide. This is part 1 on how to install vdo gauges. 3 38 speedometer 3 38 tachometer 2 116 fuel level gauge 2 116 oil pressure gauge 2 116 water temperature gauge 2 116 volt gauge wiring harness and sending units are not included with sport comp mechanical ultra lite mechanical phantom mechanical and concourse series gauges.
Follow this wire to a junction and attach the wire from pin 4 at this junction ie. A switched 12 or 24 volt wire can be found coming from the ignition switch. Vdo water temperature gauge wiring diagram. 310 105 250f water temperature gauge use with vdo sender 12v learn more. Refer to diagram d. Diagram g wiring diagram wiring of power and ground to each gauge illumination wiring.
I installed the vdo oil pressure and temperature gauges in my 1970 vw but will give you the concept on installing them in any vehicle. Vdo spin lok clamp or mounting bracket 1 5. Welcome to the vdo catalog for auto enthusiast gauges and accessories. Since 1920 weve been focused on providing our customers with the best possible instrumentation. The ground œ wire is also run in series including the light socket ground.
