Disassemble the mic and rewire using a multimeter to test connections so that the ptt switch is wired separately from the microphone element. To be certain clip the microphone off the cord and check the continuity between the white wire and the sleeve on the small plug.
Quest K Single Wire D Ring 2 Way Microphone For Kenwood 2 Pin Radios
Baofeng speaker mic wiring diagram. Its a bit tight to solder the resistors inside the plug housing but it is possible just remember to put the plug housing on the cable before soldering otherwise youll be. I suggest that before you cut the cable make sure the speakermic works with your baofeng ht. The mic connection seems fairly obvious too on the ring of the 35mm. Handheld models including the ft 10r ft 40r ft 50r ft 60r vx 1r vx 2r vx 3r vx 5r vx 110 vx 150 and any other model including the ct 44 adapter and mh34b4b speaker microphone in their accessory list utilize the non threaded 4 conductor 35mm type microphone plug which is available here. Compared to other baofeng mics this one is designed in the usa for construction sites industrial use and for all rough assignments. Speaker microphone pin out dual ptt switching.
The speaker connections seem obvious with ground on the sleeve of 25mm and other speaker connection to tip. Despite the posted diagram im still not sure how to wire up the unmodified baofeng mic to the bitx. See the original circuit diagram for the speakermic here. Graphic by electronicholas walt n3pla took the diagram to the next level and added the dual ptt and a trrs jack. It is built with a impact resistant pvc casing ip54 for shock wind dust and splash resistance. Note 2i have received a few baofeng speakermics that dont work.
This speaker mic qhm22 is the heavy duty version speaker mic you have been looking for. The wiring configuration for these is shown below. Baofeng kenwood and wouxun compatible. Herrpiluso september 8 2016 at 349 am. It is a high quality. If it does not work the cable probably wont work either.
A key question that those with a baofeng speakermic is. I harvested a cheap baofeng handheld speakermicrophone for its cable although you can buy them here the kenwood type and bought a 35mm trrs plug from digi key. You can use a common ground return for the mic speaker and ptt. Someone knows wich pin is well for direct output from discriminator. Many members are planning on using this speakermic for their mpet projects. This is a work in progress document for modifying a baofeng the wiring diagram showing how the cables need to be connected is attached.
Due to changes in baofeng manufacturing practices please trace the internal wiring of your speakermic ok now that the disclaimer is done i have with the help of cj been testing the internal wiring of the ubiquitous baofeng speakermic. I own 4 uv 5rs newest firmware version and the modulation is very good with the built in mic and with the baofeng speaker microphone on all 4.
