The other 3 wire connector on the old regulator is the stator wires. Just leave the old regulator connector that went to the battery unplugged and taped so it cant short out to your frame or some other grounded spot.
Zl 5918 Voltage Regulator Test Additionally 5 Wire Rectifier
Shindengen fh020aa wiring diagram. Shindengen fh020aa rectifier regulator super mosfet kit archived. Complete mosfet kit fh020aa diy crimp or solder kit. This wiring works on every bike i know of so far. Shindengen repsol honda team. The diy kit is a crimp or solder complete mosfet kit with everything you need to upgrade your sportbike or cruiser to a mosfet rr. Jump to latest follow.
You will still have the original wiring harness hooked up to the battery and an additional postive negative lead hooked to the battery from the new rr. The 3 feet of red black 10 gauge wire in the diagram. Wiring shindengen mosfet fh020aa. Universal fh020aa kit with 30 ampauto reset circuit breaker. Shindengen mosfet fh020aa regulatorrectifier kit kit includes weather proof connectors for shindengen regulators complete installation instructions with pictures weather proof maxi fuse holder maxi fuse holder has 10gauge wire and can handle 55amps. It does not need ignition sense or switched ignition of any kind to work it just works.
This topic is now archived and is closed to further replies. Why are you using a stock regulator wiring diagram to try to install a aftermarket new style regulator use the diagram that cam with the new part use the directions. I no longer use the maxi fuse set up in photo. The type of regulator these fit is pictured and is used on triumph yamaha kawasaki honda models. Crimping cutting stripping soldering installing heat shrink is all done. Fh012aa fh020aa mosfet regulator install help and soldering instructions for your universal mosfet kit.
The shindengen part numbers include fh0108a sh775 sh812aa. These regulatorsrectifiers charge the battery during the positive cycle of the acg output and light up the valve headlight during the negative cycle. Get an oil filter adapter. I have real shindengen rrs. Introduction to technical sponsor of repsol honda team by shindengen. Shindengen type 3 pin connector for fh020aa fh012aa type regulatorrectifiers.
If those grounds are. Fh020aa wiring diagram what i see on the wiring diagram is that the 2 ground points mentioned above feed return current for the sidestand switch. Note that the connectors are handed so they only fit in the correct position. Introductions to shindengen regulatorsrectifiers information.
