The master or pump port will send a signal activating the master solenoid if your system runs off the mains water supply or will activate your water bore pump via a low voltage relay. It doesnt matter which wire it connects to on the solenoid.
Rain Bird Cad Detail Drawings Sitecontrol Central Control
Reticulation master solenoid wiring diagram. Ok so assuming you are running off the water mains you will need to run the mp wire to your master valve. To begin wiring at the controller with the power off pull back the outer sheathing exposing the individual wires. You will need one individual wire for each solenoid valve and one common wire to be shared by all the solenoid valves. Water main master valve optional solenoid valves. Your controller has either 6 or 12 zones depending on the model you have purchased. There are 3 common wiring points for convenience any or all of them can be used.
Mike briley from access irrigation demonstrates how to wire a 24v irrigation solenoid valve into a mains powered irrigation watering controller using low voltage multi core cable. Your controller sends a low voltage signal through wiring usually 5mm for residential reticulation systems to your solenoid valves which are normally in the. You may have noticed a trend you will always require at least one extra wire. What this means is the main supply pipe which is usually pvc piping is under pressure the whole way to each solenoid. In your control box there are terminals marked c for common m or p for masterpump and then there are the numbers for solenoids 1 6 etc. A reticulation system without a master valve is always under pressure.
5 core irrigation cable. Refer to the diagram below when connecting your solenoid valves to the controller. A mainline under pressure like this is much more likely to burst or have slow leaks which may not be discovered for a long time wasting water.
