9338 black case part no. It shows the parts of the circuit as simplified shapes as well as the power and also signal links between the tools.
Kbic 125 9433 Dc Drives Chassis
Kbpc 240d wiring diagram. Variety of kbmd 240d wiring diagram. D00 162010 page 1 of 1 this supplement is for model kbpc 240d installation and operation manual part no. Contains automan switch and necessary wiring and hardware. Shunt motors only inches mechanical specifications connection diagrammm 41 kb electronics inc. A40400 until the new manual is available. Ac line wire ac line voltage to terminals l1 and l2.
Connect ground wire earth to green ground screw on case. Connect motor armature leads to a1 and a2. Automanual installation kit pn 9377 this kit facilitates mounting of kbsi 240d signal isolator into kbpc 240d. Permanent magnet pm type. Be sure jumper j3 is set to the proper. The manual must be read and understood before operating this drive.
9342 white case nema 4x ip 65 scr speed and torque control designed for dc motors rated 150 1 hp at 90vdc 125 2 hp at 180vdc tm see safety warning on page 2 the information contained in this manual is intended to be accurate. Be sure jumpers j2a and j2b are both set to the correct input line voltage 115 or 230 vac. Model kbpc 240d kb part no. Kbsi 240d pn 9431 purchased seperately. 9338 and 9342 installation and operation manual supplement a42144 rev. A wiring diagram is a simplified conventional photographic representation of an electrical circuit.
Onoff ac line switch pn 9341 this option is desirable if a positive ac line disconnect is required. Kbpc 240d 0 130 0 180 0 130 115230 9338 black 9342 white 150 150 102 102 1 75 2 15 100 200 50 100 stepdown operation 90 vdc motors with 230 vac input can cause a reduction in motor performance.
